Application: rock drills, cutting boards, drainage pumps and walk-behind breakers for construction buildings
Recommended models:
LUY140-14，LUY150-13B，LUY150-15，LUY135D-13，LUY130D-7，LUY130D-10，LUY238D-14，LUY280D-8.5
Working pressure: 7-17bar (100-250psi)
Air flow range: 5-28m3/min (176-988cfm)
Max. ambient temperature:50°C (122°F)
| Model | 050-7 | 165-13 | 210-17 | 230-14 | 250-12 | 270-10 |
| Working pressure, bar | 7 | 13 | 17 | 14 | 12 | 10 |
| Flow (m3/min) | 5 | 16.5 | 21 | 23 | 25 | 27 |
| Noise(at 7m distance, dBA ) | 70±3 | 87 | 83±3 | 79±3 | 79±3 | 79±3 |
| Fuel tank capacity, l | 67 | 250 | 300 | 470 | 470 | 470 |
| Compressor oil capacity, l | 8 | 45 | 55 | 65 | 65 | 65 |
| Engine brand | Kubota | YuChai | YuChai | CUMMINS | CUMMINS | CUMMINS |
| Engine model | V1505 T | YC6J190-T304 | YC6A260-H300 | QSL8.9-325-30 | QSL8.9-325-30 | QSL8.9-325-30 |
| Engine power, Kw | 33 | 154 | 191 | 242 | 242 | 242 |
| Norminal engine speed, rpm | 2950 | 2050 | 1900 | 2000 | 2000 | 2000 |
| Unloading engine speed, rpm | 1950 | 1300 | 1200 | 1300 | 1300 | 1300 |
| Engine inspiration | turbo charger | turbo charger | turbo charger | turbo charger | turbo charger | turbo charger |
| Dimension, mm | 2960x1350x1420 | 3000x2000x2190 | 4404x1950x2296 | 5260x1800x2630 | 5260x1800x2630 | 5260x1800x2630 |
| Weight, kg | 750 | 2200 | 3330 | 4835 | 4835 | 4835 |
